Upright Microscope XY Hot / Cold Stage Ø26mm Vacuum Chamber

This heating and cooling stage provides -190°C - 400°C and is ideal for upright optical microscopy and spectroscopy including FTIR, Raman, and X-ray, with a sealed vacuum chamber for applications where a wide temperature range is needed and control over the atmosphere is critical. The vacuum-tight configuration can be both gas purged and evacuated to low pressures to protect sensitive samples from moisture and oxygen as well as to study vacuum processes such as freeze drying.

• Sample Area Ø26mm, XY positioner sample area 15mm x 15mm
• Temperature Control Range -190°C - 400°C
• Minimum Temperature -190°C with optional liquid nitrogen cooling
• Maximum Temperature 400°C
• Software Windows software to record and export temperature time data
• Sample Loading Requires lid removal
• Sample Positioning 10mm fine travel with Vernier XY dials for remote manipulation in sealed chambers
• Atmosphere Control Sealed chamber with vacuum capability to control humidity, condensation, and oxidation.
• Frame Cooling Integrated frame cooling with optional chiller system
• Optical Access Reflected and transmitted capability
• Minimum Objective Working Distance 5mm
• Minimum Condenser Working Distance 11.5mm
• Mounting Base model includes tapped holes on frame and removable side-mounted L-brackets. Horizontal and vertical mounting adapters available for select instruments, or by custom design.
• Frame Dimensions 150mm x 86mm x 22mm
• Weight 1350g
• Manufacturer Made in USA. Custom made-to-order, lead time is 10-12 weeks.

Heating and cooling stage part #: HCS421VXY.

NOTE: This item is not returnable.
