Stage Micrometer 10mm KR842

• 10mm long scale with 1000 divisions
• Each division equals 10um (0.010mm) center to center
• Line width is 4mm (0.004mm) wide
• Numbered 0 through 10, each 1mm increment
• Lines: Chrome disposition
• Chamfer: 0.010"-0.020"
• Flatness: 2 waves or better
• Centering: Within 0.005"
• Tolerances: ± 0.0002" (±5 microns)
• Glass: 1" x 3" x 1.5mm thick ±0.2mm
• Surface Quality: 20/10
• Parallelism: 2 min.

Calibration (NIST certified) is available. If NIST certification is selected 10 most common points will be certified. If you require a specific point to be certified please note this when ordering.

NOTE: This item is not returnable.
