SCHOTT ColdVision Dual Back light 102 by 124mm

This SCOTT ColdVision dual back light has two branches, each with a back light on its end. This dual back light can be used to create crisp edge definition or soft, incident light in applications including glass inspection, edge detection, and photography. The unit comes with a protective IR filter.

NOTE: This is only a light guide. A light source for the guide must be purchased separately.

• Housing dimensions: 229mm x 127mm x 19.7mm (9" x 5" x 0.78")
• Active light dimensions (each branch): 102mm x 124mm (4" x 4.88")
• Bundle length (entire): 940mm (37")
• Length of each branch: 686mm (27")
• Diameter at input of light guide: 18.2mm (0.718")
• Tubing diameter of each branch: 17mm (0.68")
• Tubing diameter from prior to branching: 21mm (0.83")
• Bend radius: 25mm (1") / 38mm (1.5")

View the SCHOTT ColdVision Back Lights Data Sheet

SCHOTT part #s A08926 / 1210407

NOTE: This item is not returnable.
