This National Optical DC20-169 trinocular digital and video high power microscope includes an HDMI camera bundle. Allows connection to a Computer through the USB port or directly to the monitor with HDMI cable.
- Objective Lenses: DIN standard 4x, 10x, 40xR, 100xR oil immersion objective lenses. Choose from semi-plan, super high contrast or plan. You may want to view our specialized page to learn more about objective lenses.
- Eyepieces: Widefield 10x/18mm eyepiece with revolving pointer in one eyepiece. 30° inclined binocular eyepieces with dual diopters and interpupillary adjustment 54mm to 76mm. 3-position sliding rod directs light 100% to binocular eyepieces, or 100% to camera, or 70% to camera and 30% to binocular eyepieces. Accepts optional (#965-160) eyepiece reticle.
- Total Magnification: 40x, 100x, 400x, 1000x.
- Specimen Stage: Large 140mm x 135mm (5.5" x 5.25") stage with built-in, low profile, ball bearing mounted mechanical specimen holder with low-position coaxial controls, 70mm (x) by 50mm (y) movement with graduations of 0.1mm. 1.25 N.A. Abbe condenser has rack & pinion focusing, iris diaphragm, swing-out filter holder with clear blue, green and yellow filters supplied.
- Focusing: Coaxial coarse and fine focusing controls, coarse has tension adjustment, fine is graduated.
- Illumination: 3w LED with variable rheostat control. On/off switch.
- Size & Weight: Base is 185mm x 235mm (7.25" x 9.25"), 405mm (16" high), 6.3kgs (13.9 lbs.)
- Warranty: Lifetime limited warranty excluding bulb & cords. Camera has a 1-year warranty.
CAMERA SPECIFICATIONS:
- HDMI 1080P output
- Active Pixels 1920 x 1080
- Imaging area 8.5mm x 7.3mm
- SD Card Slot
- CMOS Sensor
- Computer connection allows 1920x1080 USB computer connection resolution through Motic Images Software
- Software available for download
- Connect via HDMI or USB
