Inspectis U30s 4K Overlay Assisted Inspection Gantry System

The Inspectis U30s 4K overlay assisted inspection gantry system with Inspectis OAI Software features the U30s 4K Ultra HD digital microscope with 30:1 motorized zoom on an industrial grade XY travel table top gantry stand, 27" 4K monitor, computer, and full 4K HD HDMI USB3.0 image capture device. This system includes Inspectis OAI Software with functions for automatic alignment and rescaling of overlaid images, PNG overlay on live image, and time interval overlay assisted inspection. Explore more features of Inspectis OAI Software.

• Video Output: 4K Ultra HD 2160p/30 fps switchable to FHD 1080p/60pfs
• Imager: 8.5 MP, 3840(H) x 2160(V) 16:9 format. Progressive scan CMOS image sensor
• Pixel Size: 1.62µm x 1.62µm
• Lens: High resolution motorized 30:1 zoom range with auto focus, iris control and pre-calibrated optics with automatic zoom tracking.
• Camera and lens control: Iris, Zoom, Auto Focus on/off, white balance. Optional Inspectis 2 Pedal Foot Switch and Inspectis Advanced Camera Remote Control can be purchased for hands free control of the camera. Hands free control requires both of these products.
• Environmental Protection: Camera housing is hermetically sealed to prevent entry of dust or other contaminates. ESD protection built-in to camera housing.
• Capture Device: USB image and video capture device for recording and storing images and videos.
• Illumination: Inspectis White LED Ring Light with 8 high power LEDs with 5800 K color temperature and detachable diffuser. Illumination controls for soft, smooth light adjustment. The ring light is powered directly through the AUX output of the Inspectis digital microscope.
• Stand: Industrial grade XY travel table top gantry stand available in two sizes with optional 4 direct tilt attachment:
  • Standard: X-travel 100mm - 750mm / Y-travel 100mm - 550mm
  • Long range Y- travel: X-travel 100mm - 750mm / Long range Y-travel 551mm  - 800mm.
  • Larger stand sizes are available. Contact Microscope World for details.
• Computer / Monitor: Computer with 27" 4K monitor with 3840 x 2160 resolution.
• Software: Inspectis OAI Software includes all functions of Inspectis Basics Software plus:
  • Automatic alignment and rescaling of overlaid image
  • PNG overlay on live image as digital graticule
  • Optical edge detection and DXF export
  • DXF new, import, edit and export as PNG file
  • DXF overlay on live image
  • Optical edge detection and DXF export
  • Time interval OAI (Overlay Assisted Inspection)
• Input / Output: HDMI video output, 5PMiniDin power input, 8P MiniDin for communication.
• Manufactured in Sweden.

NOTE: This item is not returnable.
