Mitutoyo M Plan Apo UV 50x Objective

Infinity corrected, metallurgical brightfield plan apochromat ultraviolet radiation range 50x objective with long working distance. Suitable for laser applications. Performance optimized for ultraviolet (266nm) and visible wavelengths. Lens features include:

• Magnification 50x
• NA 0.40
• WD 12mm
• Wavelength Range 266nm and 550nm
• Suitable YAG Laser Type Second and fourth-harmonic waves
• Focal Length in UV radiation (λ=266nm) 4mm
• Focal Length in visible radiation (λ=550nm) 4.5mm
• Resolving Power (λ=550nm) 0.7µm
• Depth of Field 1.7µm
• Real Field of View with Ø24 Eyepiece Ø0.48
• Real Field of View with 1/2" Chip Camera 0.10 x 0.13
• Parfocal Distance 95mm
• Thread Size M26
• Weight 400g

Mitutoyo Part # = 378-838-8
Note: This item is not returnable.
