The Swift M10LB-S and Swift M10LB-P digital binocular microscopes offer a 5 mega pixel integrated digital camera with a 3" LCD screen. Images and video files can be captured directly onto an SD card without the need for a computer. The LCD screen allows easy viewing of specimen and materials between lab partners sharing the microscope. The USB allows direct connection to the computer and RCA allows you to connect with existing technology such as a TV.

• Objective Lenses: Reversed quadruple nosepiece includes DIN standard 4x, 10x, 40xr and 100xr objectives. Select semi-plan or plan objectives below. If you are interested in plan phase objectives please call for information.
• Eyepieces: Binocular head with widefield 10x eyepiece with 20mm field of view.
• Total Magnification: 40x, 100x, 400x, 1000x magnification.
• Condenser: Abbe 1.25 NA spiral condenser with iris diaphragm.
• Specimen Stage: Includes mechanical stage for securing specimen.
• Focusing: Slip-clutch focusing system prevents users from damaging the focusing mechanism. Coaxial focusing system.
• Illumination: Corded microscope includes a cord-hanger for cord containment. 3.4v, LED illumination provides bright, white LED light.
• Size and Weight: 21" high, 18 lbs.
• Warranty: Swift Optical lifetime limited warranty covers defective parts and workmanship for the life of the instrument.
• Includes: Vinyl dust cover and instruction manual. Motic Images imaging software and calibration slide.

Swiftcam II imaging software / Camera specifications:

• Microscope includes built-in 5 mega pixel digital camera (when capturing to SD card, 0.3mp when capturing through software to computer) for capturing digital still images and video clips.
• 3" LCD screen folds down for protective storage. Screen pivots for ease of viewing by others.
• Includes SD card reader/writer for saving images without the use of a computer.
• Includes Motic Images software that can be used to edit, measure and annotate saved images.
• Includes USB output and cable for integration with computer.
• Includes S-Video and RCA outputs and cables for integration with TV monitors or video projectors.
• Windows XP, Vista compatible. If using a MAC OSX pictures can be downloaded with the SD card. However, on a MAC the software will not allow you to view a live image from the microscope as it does on a PC.





The Microscope World MW1-HB1 is our most popular elementary student microscopes!! This microscope is slightly smaller in size for young scientists without sacrificing high quality glass optics. The student elementary microscope includes rugged metal components and has been built with student proofing features to eliminate damage to microscope and loss of parts.

• Objective Lenses: Color coded objectives are Achromatic 4x, 10x, and 40x (retractable). Microscope objectives are mounted on a revolving objective turret. 45° inclined head for easy viewing. Head rotates 360°.
• Eyepieces: Widefield 10x eyepiece with pointer that is revolving.
• Total Magnification: 40x, 100x, 400x.
• Specimen Stage: 88mm x 82mm stage (3.5" x 3.25") includes locked-on spring activated stage clips. Disc diaphragm.
• Focusing: Coarse and fine focusing knobs with rack and pinion focusing. Rack stop protects objectives and specimen slides. Slip clutch prevents damage to focus mechanism.
• Illumination:  Your choice of the following:
• Corded microscope with tungsten illumination.
• Cordless microscope, LED Illumination, includes rechargeable batteries, auto cutoff recharger and on/off switch with rheostat control.
• Size & Weight: 11.75" high, 4 7/16" wide, 6 1/4" deep, 3.7 lbs.
• Warranty: 5-year limited warranty, excluding bulb.
• FREE ACCESSORIES: DVD "Adventures with a Microscope", Super Slide Kit and access to our password protected customer resource section of our website!

Click here to view the digital version of this microscope.

VIEW OUR UPGRADE SPECIAL!



• Magnification: This camera magnifies based on how close the MW1-LD2 is held to the object. The size of the computer monitor also affects maximum magnification.
• Focusing: Built-in focus controller includes a soft-grip focus wheel.
• Illumination: 2-step brightness control with 8-LED in ring formation.
• Camera Sensor: 1/3" CMOS chip, 1.3 mega pixels.
• Power: Directly through USB 2.0 connection.
• Computer Info: Only works with PC. Can not be used with a MAC.
• Includes: Metal stand and Software.
• Software Features: Image adjustment, capture images, video, time lapse photos, measure, add notes to images, edit images.
• Size and Weight: 10" x 7" x 3", 1lb.
• Warranty: 1-year limited warranty.

This MW5-LD2 digital stereo zoom microscope connects directly to the computer via the USB 2.0 port. The digital microscope includes software for capturing both still and moving images, making measurements and adjusting exposure.



• Objective Lenses: 1x - 4x objectives provide a zoom range from 10x - 40x when using the included 10x eyepieces.
• Eyepieces: Widefield 10x eyepieces are 45° inclined, with dual diopter adjustments, interpupillary adjustment from 55mm to 75mm.
• Total Magnification: Continuous zoom range of 10x-40. Magnification can be adjusted by adding an auxiliary lens (see chart below).
• Specimen Stage: Large 165mm wide x 220mm deep stage surface. Includes two 80mm stage plates (reversible black/white plastic contrast plate and frosted glass), blue filter for transmitted light and locked on stage clips.
• Stand: Mounted on a metal heavy duty post stand, microscope head extends to 17" for higher objects.
• Focusing: Large dual focusing knobs with slip clutch to prevent damage to mechanism. Tension adjustment eliminates focus “drift”.
• Illumination: Top light is 12v 15 watt halogen, bi-pin with directional beam and rheostat control. Bottom light is 12V 10 watt halogen, bi-pin. Lights operate together or independently.
• Size & Weight: 13" high, extends to 17" for taller objects, 11.2 lbs.
• Warranty: Lifetime limited warranty. Camera has a 1-year warranty. Software has 90-day warranty.
• Includes: Software, calibration slide, USB cable, vinyl dust cover and owner's manual.

CAMERA SPECIFICATIONS:

• 2.0 mega pixel camera built into microscope.
• 1/3" CMOS Imaging Device.
• Minimum Illumination - 3 LUX
• Connects to computer via USB 2.0 Port - self-powered through computer.
• Captures moving images at 10-20 frames per second.
• Effective pixels 1600 x 1280.
• Includes software.
• Images can be captured and saved as either .jpg, .bmp or .mig files.

SYSTEM REQUIREMENTS :

• Windows XP or above, MAC OSX
• Intel Pentium
• CPU 2 Ghz or above
• RAM 1 GB or above
• Hard Disk 500 MB or above
• Video card 128 MB or above
• CD-ROM drive
• USB 2.0 port
